Protector de Sobretensión DC 500V 20KA/2P para Sistema Solar Fotovoltaico
| Precio Neto c/u | $ 37.807.- |
| I.V.A. c/u | $ 7.183.- |
| Precio Final c/u | $ 44.990.- |
-0%
Suntree Protector de Sobretensión DC 500V 20KA/2P
Especificaciones:
| SSPD series surge protector | SSPD | |
| PV DC-specific(LEC 66143-1/EN 61643-1 1) | ||
| Pole | 2P | |
| Electrical Parameter | ||
| Classified test | II | |
| Uoc max(V DC) | 500 | |
| Uc(V CD) | 500 | |
| In(8/20)us(KA) | 20 | |
| Imax(8/20)us(KA) | 40 | |
| Up(KV) | 2 | |
| Remote control and indication | ||
| Indication window | ||
| Piug-in Module | ||
| Remote signal contact | maximum working voltage(V) | 250 AC/30V DC |
| maximum working current(A)IA(250V/AC | IA(250V/AC) | |
| IA(30V DC | IA(30V/AC) | |
| Wiring&installation | ||
| Wiring capacity(mm2) | Hard wire | 4~25 |
| Flexible wire | 4~16 | |
| Stripping length(mm) | 10 | |
| Terminal screwa | M5 | |
| Torque(Nm) | Main ciruit | 3.5 |
| Remote signal contact | 0.25 | |
| Protection class | All profile | IP40 |
| Connection port | IP20 | |
| Installation environment | NO obvious shock and vibration | |
| Altitude(m) | ≤2000 | |
| Working Temperature | -3.0~+70 | |
| Relative humidily | 30%~90% | |
| How to install | Installed with H-7.5/DIN35 steel mounting rail | |
| Size(mm)(W×H×L) | W | 36 |
| H | 90 | |
| L | 67.6 | |
| Weight(kg) | 0.24 |
